Led Outdoor Lighting Outdoor Waterproof Connectors 2Pin 3Pin DC
IP68 Connector
Product Features
1. IP67 waterproof rating for outdoor using
2. Quick-connect Self Locking design for convenient and easy DIY
3. Panel mount socket & Butt joint available
4. Soldering & Screw type terminals available
5. Accepted Max. Cable OD: 12 mm
6. Field installable, soldering or screw connection, crimpping
connection available
7. We could help to attach cable in any length and process
terminals if required
8. UL, TUV, CCC, CE, RoHS approved
Our Services
* Accepted Max. Cable OD: 9 mm
* Field installable, soldering or screw connection
* UL, TUV, CQC, CE, RoHS approved
* High quality with 12 months waranty
* Pin range: 2, 3, 4 , 5 , 6 , 7 , 8
* We could help to attach cable in any length and process terminals
if required
* Customer's drawings and designs are welcome, as we have our own
professional R&D team to provide
you various solutions
Product Parameter
| Connector | Outdoor waterproof connectors |
| 2P 3P 4P 5P 6P 8PWaterproof Cable Connector |
| Wire | 20~16Gauge,0.5-1.5MM² |
| Color | Black/Blue/Yellow |
| Length | Optional |
| Voltage Rating | AC300V |
| Current Rating | 1A~20A |
| Times Of Plug | 500 |
| Withstand Voltage | 1.5KV |
| Temperature Rating | —40~+105℃ |
| Waterproof Level | IP67 |
| Max Cable OD | 9mm |
| Pin Numbers | 2-22 wires |
| Certifications | CE/UL/TUV/ROHS |
| Application | Our products are widely used in LED lighting, Flexible strip
outdoor display, electrical equipment, automation machines,
electrical vehicle and etc...
|
Widely used M19 lock type Connector:
Great suitable for Outdoor LED light, LED Display, LED Street Lamp
lighting, Stage lighting, LED equipment, Communication Equipment,
Power, Automotive, grating, external wiring, CCTV, factory
automation control, wireless bridge and other places need
waterproof joint use.
IP67 Waterproof connector plug:
Moisture-proof and Dust-proof, never leave your precious wires
exposed and have good protection on them,this outdoor electrical
box is safe for home, garden or outdoor lighting.
Easy installation M19 cable connector wiring:
Easy connection, Convenient install, DIY tools, and no need to
pinch-off cable electrical plastic sets, just unscrew the ends of
waterproof connector, connect the wire correctly: N for Neutral
wire, G for Ground wire, L for live wire.
Product Dimention
